Automatic Monitor Fire Water Cannon 35

Product Description

The Automatic Monitor /Detection Fire Water Cannon CV 35is a high-tech fire protection product t hat combines infrared and ultraviolet, signal processing, communication control, computer and mechanical transmission technology. When the source of fire is discovered, The device starts immediately, Intelligent scanning of fire sources, Determine the specific location of the fire source as quickly as possible, The controller sends out a fire alarm signal, Start the water pump at the same time, Open the solenoid valve, The device aims at the fire source to spray water to extinguish the fire. After the fire source is extinguished, The controller then issues a command to stop water injection. If a new fire source is discovered, The fire extinguishing device will repeat the above process, Return to the monitoring state after all fire sources are extinguished.

Technical Parameters

model	ZDMS 0 . 6 / 5 S - CV 3 0	ZDMS 0 . 6 / 1 0 S - CV 3 5	Positioning time	≤ 30 seconds
Fixed work stress	0.6MPa		Voltage/power consumption	AC 220 V/Monitor: 1 W, Scan: 50 W
Limited Data	5L/s	10L/s	communication method	RS 485 (communication with on-site manual control box)
Install valve flange	DN 32		Horizontal angle of rotation	360°
Maximum protection radius	30 m	35m	pitch angle	- 90°～30°
Installation height	6～15m		Implementation standard number	GB 25204-2010

Product Advantages

The automatic tracking and positioning jet fire extinguishing device sprays water in a columnar shape. Long range, The scope of protection is wide, Strong fire extinguishing ability. The system only extinguishes fire in the fire area. It has basically no impact on fire-free areas. This reduces the losses caused during the fire extinguishing process to a minimum.

This product is mainly used in tall spaces. for example: Airports, stadiums, stations, factories, hospitals, shopping mall halls, convention and exhibition centers and other places.
